Product Features
- LiFePO4 technology. Ultra-safe Lithium Iron Phosphate.
- Built-in Battery Management System (BMS).
- Light weight & compact.
- IP56 Water & dust resistant.
- Highly durable ABS enclosure.
- Drop in lead acid replacement in terms of physical size (Note: ensure that your charge controller and/or inverter are lithium compatible).
Technical Specifications
General
- Battery Technology: LiFePO4 (Lithium Iron Phosphate).
- Capacity: 1.4kWh or 1400Wh @C10, 25°C.
- Nominal Output Voltage: 13 VDC.
- Operating Voltage Range: 14.4 VDC to 11.6 VDC
- Cycle Life @ 100% DoD > 2000 cycles (1400 Wh @C10, 25°C).
- Cycle Life @ 80% DoD > 3000 cycles (1120 Wh @C10, 25°C).
- Cycle Life @ 50% DoD > 5000 cycles (700 Wh @C10, 25°C).
- Operating Temperature Range: Charge: 0°C – 45°C | Discharge: -20°C – 65°C.
- Dimensions (mm): 342 x 173 x 220mm (W x D x H).
- Weight: 16 kg.
- Warranty Period: 3 Years.
- Max. 4 in series, max. 2 in parallel
- Recommended to not expand if the difference between the oldest & newest battery is more than 12 months.
Charge / Discharge
- Bulk Voltage: 14.4 VDC.
- Discharge Voltage (min.): 11.6 V.
- Charge Current (max.): 52.5 A continuous.
- Discharge Current (max.): 110 A continuous; 160 A burst (30 seconds).
- Self-discharge Rate: < 3% per month.
- Charge & Discharge Efficiency: 96% – 99% @C1
Protection
- Environmental Protection: IP56
- Over-current Protection: 110 A
- Over-voltage Cut-out: 15.6 V
- Under-voltage Cut-out: 10.0 V
